Brilliant Halton Dual Wattage CCT LED Batten

Description of the image
SKU: 22330/05

The Halton CCT LED Batten is a one box solution. Its ability to not only change the wattage but also the colour temperature makes an ideal replacement for traditional battens.

  • Suitable for replacement of traditional battens as well as for new installations
  • 160mm widebody and low profile design
  • Designed for quick and easy installation and maintenance
  • Large terminal blocks and cable entry
  • High efficiency SMD LED chips, CRI > 80, 120 degree beam distribution
  • Non-dimmable LED driver
  • Easy selectable colour changing temperature (CCT) with an inbuilt switch
  • Dual-Power Selectable: 22W/40W (Through DIP switch)
  • Rated lifetime: 30,000hrs @40°C Ambient
Family
Halton
Construction
Steel (frame), Polycarbonate (diffuser)
Operating voltage
220-240V / 50Hz
Light type
LED
Light wattage
22W/40W Switchable
Light lumens
4000lm
Colour temperature
3000K/4000K/5700K
Colour rendering index
≥80
Ingress protection
IP20
Class
Class I (1)
Installation
Must be installed by a licensed electrician
Beam angle
120°
Standards
AS/NZS 60598.1, AS/NZS 60598.2.2, CISPR15
Warranty
3 year
